7.5 KW Automatic Steel VCD CD Fire Smoke Damper Frame Roll Forming Machine

Brand Name : SUSSMAN

Model Number : SS-FD

Certification : CE

Place of Origin : WUXI CHINA

MOQ : 1 set

Price : negotiable

Payment Terms : T/T, L/C

Supply Ability : 10 sets per month

Delivery Time : 65-75 days after deposit

Packaging Details : standard packing

Main Motor Power : 7.5KW

Material Thickness : 1.5-2.0mm

Rolling Stations : About 16 Stations

Way Of Drive : 1.2 inch chain

Roller Material : Gcr15 coated with chrome

Hardness : HRC58-62

Contact Now

7.5 KW 1-1.5mm Thickness Metal VCD CD Fire Smoke Damper Frame Roll Forming Machine





Fire Damper Technical Parameter


  Items Specifications
Material of coil Material Thickness 1.0-1.5 mm galvanized coils
  Un Coiler 3 tons hydraulic
Servo feeding Motor Delta 1.8kw
Punching device Punching 4 sets of punching die
Forming system Forming Speed About 2-3pieces/min
  Roller Stations About 16 stations
  Roller Material

Gcr15 coated with chrome



  Maim Motor Power 7.5kw
  Motor cutting Power 5.5kw

Cutting

system

Material Of Cutting CR12mov with quench treatment
  Hardness HRC58-62
  Tolerance +-1.5mm
  Cutting blades 1 set
Electrical control system Electric Source

380V, 50HZ,3 phase

Also can satisfy Customer’s requirey

  Control System PLC Delta as list in the note
  Weight About 8 tons
  Way Of Drive 1.2 inch chain
Machine size mm 10000mm*700mm*1000mm






Fire Damper Main Components



     S.N

   Equipment name


   Quantity
      1.

    5T passive un-coiler


    1 set
      2.

    Main roll forming machine



    1 set
      3.

    Hydraulic cutting


    1 set
      4.

    Control system (including control box)


    1 set
      5.

    Punching


    2 sets
















Working Flow of  Fire Damper

Decoiler----Feeding---Roll forming---Cutting---Run out tables



 7.5 KW Automatic Steel VCD CD Fire Smoke Damper Frame Roll Forming Machine



Samples



7.5 KW Automatic Steel VCD CD Fire Smoke Damper Frame Roll Forming Machine



7.5 KW Automatic Steel VCD CD Fire Smoke Damper Frame Roll Forming Machine



Advantage for Fire Damper

1. Reasonable Price
2. High Quality
3. 12 Months Warranty
4. More Than 10 Years Experience
5. Durable
6. Reliable
